Splendor Series

8-9.5 Meters Medi Bus

Add to Inquiry Basket

Product Features





















Technical Specification

Model: 9.5 Meters Medi Bus 9 Meters Medi Bus 8.5 Meters Medi Bus 8 Meters Medi Bus
Dimension（mm）9545×2500×3480
Wheelbase (mm)4700
Angle of Approach / Departure(°)10°/9°
Fornt / Rear Overhang1970/2875
Curb Weight（kg）14000
YC6J245-30/ISDe270-30/ISDe245-30/YC6A240-20/YC6G240-30
Transmission6 MT(Options:5 MT)
Suspension SystemLeaf Spring Suspension(Options:Air Suspension)
Front/Rear Axle 4.5T/9.5T
Brake SystemFront/Rear Drum Type(Options:Disc Type,Retarder)
Door ArrangementFront Door
Rated Seat CapacityUp to 41
Dimension（mm）8995×2500×3480
Wheelbase (mm)4300
Angle of Approach / Departure(°)11°/8°
Fornt / Rear Overhang1905/2790
Curb Weight（kg）13000
YC6A240-20/C230-20/YC6J245-30/ISDe245-30/ISDe230-30/ISDe210-30
Transmission6 MT(Options:5 MT)
Suspension SystemLeaf Spring Suspension (Options:Air Suspension)
Front/Rear Axle 4.5T/9.5T
Brake SystemFront/Rear Drum Type(Options:Disc Type,Retarder)
Door ArrangementFront Door
Rated Seat CapacityUp to 39
Dimension（mm）8540×2500×3300
Wheelbase (mm)4100
Angle of Approach / Departure(°)11°/10°
Fornt / Rear Overhang1805/2635
Curb Weight（kg）11300
YC4G200-20/YC6J220-30/EQB210-20/C230-20/ISDe245-30/YC6J230-20
Transmission6 MT(Options:5 MT)
Suspension SystemLeaf Spring Suspension(Options:Air Suspension)
Front/Rear Axle 4.2T/8T
Brake SystemFront/Rear Drum Type(Options:Disc Type,Retarder)
Door ArrangementFront Door
Rated Seat CapacityUp to 35
Dimension（mm）8030×2500×3300
Wheelbase (mm)3800
Angle of Approach / Departure(°)12°/11°
Fornt / Rear Overhang1770/2460
Curb Weight（kg）10580
YC4G180-20/YC4G200-20/ISDe180-30/WP5．180E30
Transmission6 MT(Options:5 MT)
Suspension SystemLeaf Spring Suspension(Options:Air Suspension)
Front/Rear Axle 3.6T/7.2T
Brake SystemFront/Rear Drum Type(Options:Disc Type,Retarder)
Door ArrangementFront Door
Rated Seat CapacityUp to 33

Downloads

Below you can find links to more features, facts and figures.

Splendor Series(PDF, 1.27Mb)

Technical Specification(PDF, 356.40Kb)
