Triumph Series

Tourism Coach & Intercity

Add to Inquiry Basket

Product Features
Technical Specification
Downloads
Make an Inquiry

Product Features

Technical Specification

Model: 12 Meter Coach and Inrtcity 11 Meter Coach and Inrtcity 10 Meter Coach and Inrtcity

Dimension（mm）	12000×2550×3690
Wheelbase (mm)	6300
Angle of Approach / Departure(°)	9°/8°
Fornt / Rear Overhang (mm)	2350/3350
Gross Weight (KG)	18000
Rated Seat Capacity	Up to 55
Transmission	6 MT
Suspension System	Air Suspension (Options:Leaf Spring Suspension)
Brake System	Front Disc(Options:Drum Type)/Rear Drum Type(Options:Disc Type)with Retarder
Front/Rear Axle	6.5T/13T
Door Arrangement	Front Door(Options:Central Door)

Dimension（mm）	10990×2500×3600
Wheelbase (mm)	5550
Angle of Approach / Departure(°)	9°/9°
Fornt / Rear Overhang (mm)	2250/3190
Gross Weight (KG)	16500
Rated Seat Capacity	Up to 51
Transmission	6 MT
Suspension System	Leaf Spring Suspension(Options:Air Suspension)
Brake System	Front/Rear Drum Type(Options:Disc Type) with Retarder
Front/Rear Axle	5.5T/11T
Door Arrangement	Front Door and Central Door

Dimension（mm）	10490×2500×3600
Wheelbase (mm)	5200
Angle of Approach / Departure(°)	9°/9°
Fornt / Rear Overhang (mm)	2120/3170
Gross Weight (KG)	15000
Rated Seat Capacity	Up to 47
Transmission	6 MT
Suspension System	Leaf Spring Suspension(Options:Air Suspension)
Brake System	Front/Rear Drum Type(Options:Disc Type,Retarder)
Front/Rear Axle	5.5T/11T
Door Arrangement	Front Door(Options:Central Door)

Downloads

Below you can find links to more features, facts and figures.

Triumph Series(PDF, 572.62Kb)

Technical Specification(PDF, 2.26Mb)
